Primary Headworks
Tracks and measures all incoming wastewater entering the treatment facility.
The Headworks is the first stage of the wastewater treatment process and serves as the facility’s primary treatment area, where raw wastewater enters the plant for initial screening, debris removal, grit separation, odor control, and flow monitoring. This critical process helps protect downstream equipment, stabilize incoming flows, remove damaging materials, and prepare the wastewater for advanced biological treatment while supporting efficient and reliable plant operations.
Secondary Treatment
Uses beneficial microorganisms and settling processes to biologically remove pollutants and separate treated water from solids.
Secondary Treatment is the biological stage of the wastewater treatment process where microorganisms break down and remove dissolved organic matter and nutrients from the wastewater. Within the aeration basins, oxygen is introduced to support microbial activity before the water flows into secondary clarifiers, where gravity separates the biological solids from the treated water. A portion of the settled microorganisms is returned back into the treatment process to maintain biological stability, while excess solids are removed for further processing and biosolids handling.
Tertiary Treatment
Provides advanced filtration and disinfection to produce high-quality reclaimed water suitable for reuse or safe environmental discharge.
Tertiary Treatment is the final stage of the wastewater treatment process where the treated water undergoes advanced filtration and disinfection before reuse or discharge. During this process, fine suspended solids are removed through filtration systems, and sodium hypochlorite is added within the chlorine contact basins to destroy harmful microorganisms and ensure the water meets strict regulatory and reclaimed water quality standards.
Distribution
Stores, monitors, and distributes high-quality reclaimed water for approved non-potable reuse applications.
The Distribution System manages the storage, pumping, monitoring, and delivery of reclaimed water after the treatment process is complete. High-quality treated water is stored in large tanks and distributed through a controlled pumping network for approved non-potable reuse applications such as irrigation. Automated controls, monitoring systems, and safety protections continuously verify water quality, regulate system pressure, and ensure only compliant reclaimed water enters the distribution network, while reject systems and deep injection wells provide backup handling and disposal options when reuse conditions are not met.
Mechanical Bar Screens
Removes large debris and solids to protect pumps and downstream equipment.
Mechanical step screens remove large debris and solid materials from incoming wastewater before they can enter downstream treatment systems. Materials such as wipes, plastics, rags, and paper products are captured on the screen surface and lifted out of the flow using a motorized stepping mechanism, helping protect pumps, piping, and treatment equipment from clogging, damage, and excessive mechanical wear.
Grit System
Removes sand, grit, and heavy particles that can damage infrastructure.
The grit removal system removes heavy inorganic materials such as sand, gravel, coffee grounds, and eggshells from the incoming wastewater stream before they can damage downstream equipment. By slowing the flow within controlled chambers, heavier particles settle to the bottom while lighter organic material continues through treatment, helping reduce equipment wear, prevent sediment buildup, and maintain overall system efficiency.
Odor Control System
The odor control system captures and treats foul air generated during the early stages of wastewater treatment. Ventilation systems pull odorous air from enclosed process areas and route it through specialized treatment systems such as chemical scrubbers, biofilters, or activated carbon units to remove compounds like hydrogen sulfide (H₂S), helping reduce odors, protect infrastructure from corrosion, and improve conditions for both plant staff and surrounding communities.
Aeration Basins
Uses oxygen and beneficial microorganisms to biologically break down pollutants and remove nutrients from wastewater.
Aeration Basins are a critical part of the secondary treatment process where beneficial microorganisms biologically treat the wastewater by consuming organic pollutants and nutrients. Air is introduced into the basins to provide oxygen and create the conditions needed for microbial activity, allowing the system to remove contaminants such as organic waste and ammonia as the wastewater flows through different treatment zones. This controlled biological process helps improve water quality, stabilize treatment performance, and prepare the water for solids separation in the secondary clarifiers.
Secondary Clarifiers
Separates biological solids from treated water using gravity settling before disinfection and final treatment.
Secondary Clarifiers are large settling tanks used to separate biological solids from treated wastewater after the aeration process. As the wastewater enters the clarifiers, gravity allows the activated sludge to settle to the bottom while clarified water rises to the surface and flows onward for additional treatment and disinfection. A portion of the settled solids is returned to the aeration basins to maintain the biological treatment process, while excess sludge is removed for biosolids handling and further processing.
Sludge Holding Tanks
Temporarily stores treated water that does not meet reuse standards to protect public health and maintain system compliance.
The Reject Storage Tank temporarily stores treated water that does not meet reclaimed water quality requirements. If monitoring systems detect issues such as improper chlorine levels, turbidity, or other water quality concerns, the flow is automatically diverted into the reject storage system instead of entering the reclaimed water distribution network. Stored water can later be retreated, redirected back into the process, or safely disposed of through approved systems, helping maintain safe operations and regulatory compliance.
WAS Pumps
Waste Activated Sludge (WAS) Storage Tanks temporarily hold excess biological solids removed from the secondary treatment process to help maintain stable plant operations and treatment efficiency. Inside the tanks, the sludge is continuously mixed to prevent settling, reduce odors, and maintain consistent sludge quality before being sent for dewatering, further treatment, or disposal. These tanks also help balance fluctuations in sludge production and provide a steady, controlled flow to downstream biosolids handling systems.
Return Activated Sludge (RAS Pumps)
Return Activated Sludge (RAS) is the process of recycling settled biomass from a secondary clarifier back into the aeration basin of a wastewater treatment plant. This maintains a stable, concentrated population of hungry microorganisms to break down incoming raw sewage and ensures continuous biological treatment.
Automatic Backwash Filters
Automatically removes fine suspended solids from treated wastewater while continuously cleaning the filtration system during operation.
Auto Backwash Filters are advanced filtration systems used during tertiary treatment to remove fine suspended solids remaining after secondary clarification. As treated water flows through the filter media, small particles are captured to improve water clarity and overall effluent quality before disinfection and reuse. The system continuously monitors filter performance and automatically initiates a backwash cleaning cycle when needed, allowing accumulated solids to be removed without interrupting normal operation.
Chlorine Contact Tanks
Disinfects treated wastewater by introducing chlorine and providing controlled contact time to destroy harmful microorganisms.
The Chlorine Contact Basins and Sodium Hypochlorite Feed & Storage System work together to disinfect treated wastewater before reuse or discharge. Sodium hypochlorite, a liquid chlorine solution, is stored onsite and carefully metered into the treated water stream, where the chlorine contact basins provide the necessary time and flow conditions for the disinfectant to effectively destroy harmful bacteria and pathogens. This process helps ensure the reclaimed water meets strict regulatory standards while protecting public health and supporting safe environmental discharge or non-potable reuse applications.
Sodium Hypochlorite System
Stores and precisely delivers sodium hypochlorite to disinfect treated wastewater and maintain required water quality standards.
The Sodium Hypochlorite System stores and delivers liquid chlorine used during the final disinfection stage of the treatment process. Chemical feed pumps precisely meter sodium hypochlorite into the treated wastewater at controlled rates, helping destroy harmful microorganisms and maintain the required chlorine residual. Automated monitoring and dosing controls help ensure reliable disinfection while supporting regulatory compliance and the production of high-quality reclaimed water.
Effluent Transfer Pumps
Transfers treated effluent through the facility for final treatment, storage, reuse, or approved disposal.
The Effluent Transfer Pumps move treated wastewater from one stage of the facility to the next, providing the flow and pressure needed to support final treatment and water management operations. The pumps help maintain consistent movement of effluent toward storage, reclaimed water distribution, or approved disposal systems while responding to changing plant flows and operating conditions. Reliable pump operation is essential for maintaining continuous treatment and preventing disruptions throughout the facility.
Reclaim Water Storage Tanks
Stores high-quality reclaimed water before it is pumped into the reuse distribution system.
Reclaimed Water Storage Tanks provide temporary storage for highly treated reclaimed water before it is distributed for approved non-potable reuse applications such as irrigation. These large storage tanks help balance fluctuations between treatment plant production and customer demand while supporting stable system pressure and continuous water availability. Integrated monitoring and automated controls help ensure only reclaimed water meeting strict quality standards is stored and delivered throughout the distribution network.
Reclaim Water Pumps
Pumps reclaimed water from storage tanks into the distribution system for approved non-potable reuse applications.
Reclaimed Water Storage Pumps transfer highly treated reclaimed water from the storage tanks into the reuse distribution network for applications such as irrigation and other approved non-potable uses. These pumps automatically adjust flow and pressure based on real-time system demand using integrated sensors and control systems, helping maintain stable operation, reliable water delivery, and efficient distribution throughout the reclaimed water system.
Deep Injection Well
Safely disposes of treated wastewater deep underground when reclaimed water cannot be reused.
Deep Injection Wells provide a regulated disposal method for treated wastewater when reclaimed water demand is low or when the water does not meet reuse standards. The system pumps treated effluent deep underground into isolated geological zones far below drinking water aquifers, helping ensure environmental protection and regulatory compliance. These wells allow the facility to continue operating reliably under changing conditions while safely managing excess treated water that cannot be distributed through the reclaimed water system.
